Silver Salute Bottom View Silver Salute Schematic Silver Salute Demensions
Super Star Silver Salute
Description The SILVER SALUTE is Superior Quality Base Microphone For the CB. And Amateur Communications Enthusiast. That is entirely chrome plated and features a grip-to-talk bar and a press-to-talk bar. The microphone head plugs into the top of the mast and is locked on by means of a union nut (See drawing on other side).
Super Star Silver Salute Base Microphone
Specifications Type: Frequency Response: Sensitivity: Impedance: Cable: Housing: Finish: Battery: Weight: Size:
Dynamic MIC See Frequency Response Curve on other side -12 ± 2dB(at 1KHz) 600 Ohms Five conductor (one conductor shielded) coiled cord that extends to 2.7M (9ft.) Die cast zinc alloy Polished chrome Standard 9 volt battery (not included) 1.10Kg(2.41b, 38.8oz) 254mm(10") high x l23mm (4.8") width (Bottom)
Silver Salute Demensions Silver Salute Frequency Response Graph Silver Salute Schematic Silver Salute Bottom View
Volume Adjustments At a speaking distance of approximately 2 inches (or the position you prefer) starting with the external volume control set fully counter-clockwise, adjust the volume control for the correct modulation level. Rotating the volume control clockwise increases the volume Battery Replacement Remove the bottom cover by removing the four screws. Carefully lift off the cover Unsnap the battery from the battery connector and install a new battery. Carefully replace the bottom cover and fasten with the four screws previously removed.
