CBWI October 2001 RF Limited XTR-2018 Xtreme™ Echo Mic

Echo Volume

Echo Delay

Echo Switch

Sound Effect

2 through10

Infinity

Cyborg™

2 through10

Infinity

Stadium Sound™

8 through 10

Infinity

Endless Echo™

2 through10

Double Talker™

RF Limited XTR-2018 Xtreme™ Echo Mic This is the latest echo mic from RF Limited. As the name suggests, it's turbo echo to the extreme! In addition to the features of the EC-2018 Turbo, it has Cyborg™ Robotic Voice, which is another name for Alien Voice™, Endless Echo™, Stadium Sound™, Double Talker™, and a richer tone quality that can be best described as studio quality. To best describe the Double Talker™ effect I have to mention the Astatic Echo Max 2000™. It is the same as their Slapback™ effect. It is a one time repeat instead of a fading echo. Like the EC-2018 Turbo, the EC-2018XTR runs off of a 9 volt battery. I strongly recommend an alkaline type or if even longer life is desired, pick up a Radio Shack 9 volt lithium battery. Below is a table with the approximate settings for desired effects.

The most common wiring available is the 4-pin Cobra/Galaxy/Uniden, although it can be wired to any radio on the market today. I've also tried one on a Tram D201 tube rig. It definitely has a studio quality sound on this rig. I've also used one with a Magnum Delta Force, setting the mic and the radio internal turbo echo to different settings in order to create a different sound effect with, awesome results. The mic is so clean it works well in conjunction with other echo boards. They are available from Bob's CB Shop for $69.95. http://bobscb.com

EC-2018 Xtreme™ Front With Battery Ind. LED

EC-2108 Xtreme Top View

EC-2018 Xtreme Rear View

EC-2018 Xtreme™ Front With Battery Ind. LED

The EC-2018 Xtreme™ Also Has A Very Flexible 3 Meter Coiled Cord

EC-2018 Xtreme™ Wire Color Code

Wire Color

Wire Function

Black

PTT Common

Shield

Ground

Red

Audio

White

PTT TX

Blue

PTT RX

Bob F EchoMax 2000™ and Slapback™ are trademarks of Astatic Corporation. All other trademarks listed are trademarks of RF Limited.

EC-2018 Xtreme™ Specifications

Sensitivity

-25dB @ 1 KHz (at maximum output and minimum echo)

Impedance

1 K Ohm

Frequency Response

150 - 3 KHz

Echo Frequency Response

200 - 3 KHz

Echo Time

2 Seconds

Maximum Battery

9 Volt Preferably Alkaline

Internal Noise

0.5mV or Less

Microphone Element

ECM Type

Below are audio samples of the different effects. Notice the difference in tone quality between the EC-2018 Turbo and the EC-2018 Xtreme™. All the sound effect were recorded with the same equipment at the same settings and with no equalization. The only difference is the microphones, and they are stock from the factory.
